Specifications

Details

Product code RBSXTsq5nD

Architecture MIPSBE

CPU AR9344

CPU core count 1

CPU nominal frequency 600 MHz

Dimensions 129x129x34mm

RouterOS license 3

Operating System RouterOS

Size of RAM 64 MB

Storage size 16 MB

Storage type FLASH

MTBF Approximately 100'000 hours at 25C

Tested ambient temperature -40°C to 70°C

Suggested price $46.00

Powering

Details

Number of DC inputs 1 (PoE-IN)

Max power consumption 6 W

Cooling type Passive

PoE in Passive PoE

PoE in input Voltage 10-30 V

Wireless specifications

Details

Wireless 5 GHz Max data rate 300 Mbit/s

Wireless 5 GHz number of chains 2

Wireless 5 GHz standards 802.11a/n

Antenna gain dBi for 5 GHz 16

Wireless 5 GHz chip model AR9344

Wireless 5 GHz generation Wi-Fi 4

Ethernet

Details

10/100 Ethernet ports 1

Certification & Approvals

Details

Certification CE, FCC, IC, EAC, ROHS

IP IP54

Wireless specifications

5 GHz Transmit (dBm) Receive Sensitivity

6MBit/s 25 -96

54MBit/s 20 -80

MCS0 25 -96

MCS7 19 -75
