Wireless

 Standards

 IEEE 802.11b/g/n 2.4GHz

IEEE 802.11a/n/ac 5GHz

Signal Rate

 Up to 300Mbps 2.4GHz

Up to 866Mbps 5GHz

Frequency Range

2.4-2.4835GHz and 5.150~5.85GHzTransmit Power

20dBm(MAX)Data Transfer Rates

802.11n:

40MHz (300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)

20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)

801.11g:

(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)

802.11b:

(11Mbps, 9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)Wireless Modes

 Router, AP, RepeaterWireless Security

Support 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES)Hardware

Standards

  IEEE 802.11b/g/n/acInterface

 1*10/100Mbps Auto MDI/MDIX RJ45 LAN/WAN Port

 2x2 11b/g/n/ac 2.4/5 GHz dual band

Buttons

1x WPS button/ 1x Reset to default button

LED Indicators

Power/Single Good/Single Poor/WPSAntenna

 2*Omnidirectional Antenna

Power Supply

 DC 3.35V/3A

Dimensions

 (L x W x H)

 80mm*76.5mm*54mm

 Others

 Support IPv4 / IPv6 / DHCP server/ LAN IP set / Firmware Upgrade/

 Diagnostic / Ping Watchdog / System Log

Advanced

Firmware Upgrade, Factory Defaults, RebootOthers

Certification

FCC, CE, EACEnvironment

Operating Temperature: 0℃~40℃

Storage Temperature: -40℃~70℃

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensingPackage

1* E3

1* Quick Installation Guide (Multilingual)
